Maximum work height: 7.78 m
Measurements: 78 x 178 cm h: 198 cm
Maximum capacity: 200kg (operator + load)
Weight of the machine: 860 kg
Standard colouring: grey and orange. Custom colours on request.
Double side access
PICKING PLATFORM:
Load capacity: load up to 100 kg
Closable: to save space
Adjustment: electric
Comfortable and ergonomic: the position of the platform prevents excessive strain on the operator
Some areas of use:
Picking and/or storage of small parts or bulk goods, organisation of warehouses and shelves in factories, shopping centres, wholesale shops, etc.
Elevah 80 Move Picking: the ideal picking platform, approved as a forklift truck for storage
Elevah 80 move picking is the compact platform designed for picking, storage, organisation and restocking of warehouses and shelves and logistics.
It allows you to work up to a maximum height of 7.78 m and to pick up a maximum of 100 kg.
The compactness – only 78×128 cm – and the zero turning radius allow the operator to work easily and quickly, even in narrow areas, and to smoothly drive even if there is little room for manoeuvre.
The picking plate is foldable in order to further minimize the size of the platform. The access is comfortable and easy thanks to the double-sided entrance.
Not only does elevah 80 move picking make work safer, but also easier and quicker: the picking plate is electrically adjustable in height, allowing ergonomic loading and unloading and minimising efforts.
Easy and comfortable to move, it can be driven with one hand thanks to the joystick.
In the equipment and accessories section, you can find all the standard components and accessories to customise your Elevah 80 move picking.
- Accidental opening block
- Frontal, rear and ceiling anticollision radar
- Basket height block max. Height 1,95
- Bluespot1 and bluespot2 (driving direction indicator light)
- Anti-crush protection under the basket
More options:
- Different colours of the machine upon request
- Directional lock of the swivel wheels
- Loading and unloading system from the van
Battery charger with retractable cable as standard (Not present if the optional BKIT is selected)
The machine can work at temperatures between -10° C and +40 °C
